19kg Total Weight
Featuring an aluminum alloy frame, this wheelchair weighs a mere 19kg with the battery—half the weight of conventional models—yet it safely supports up to 100kg.
3-Second Folding
Lightweight and folds in just 3 seconds for ultimate portability and storage. Quick 3-second fold and lightweight design allow for easy transport and storage, wherever you go.
3-Second Folding
Lightweight and folds in just 3 seconds for ultimate portability and storage. Quick 3-second fold and lightweight design allow for easy transport and storage, wherever you go.
完美性能
持久續航力
採用高容量電池時，一次充電提供高達30km續航力，充沛的電力滿足日常出行。
強勁動力
180W*2充沛的動力輸出，能實現12度或斜率20%以上的上斜動力，遠勝對手。
EABS電磁剎車
採用創新離合剎車器，停車時安靜無噪，跟傳統煩人的電磁制動系統說再見。
Suitable For Traveling
The wheelchair can be checked in after detaching the battery while the batteries can be carried on board, no more restrictions on traveling.
Battery Allowed Onboard
Wheelchair Checked Baggage
Battery Allowed Onboard
Wheelchair Checked Baggage
Incomparable User Experience
A simple and user-friendly operation interface which provides a easy operating experience.
Switchable Controller
The electric controller can be freely positioned on the left or right side of the frame, accommodating users with different dominant hands; it can also be easily switched to manual mode for convenient caregiver pushing.
Switchable Controller
The electric controller can be freely positioned on the left or right side of the frame, accommodating users with different dominant hands; it can also be easily switched to manual mode for convenient caregiver pushing.
Switchable Controller
The electric controller can be freely positioned on the left or right side of the frame, accommodating users with different dominant hands; it can also be easily switched to manual mode for convenient caregiver pushing.
Foldable Armrest Design
Providing a 3-way entry and dining-on-the-device feature, able to reduce the pressure of the caregivers.
Custom comfort cushion
Our custom air fiber cushion provides exceptional comfort and breathability, superior stain resistance and quick-drying compared to standard foam cushions, ensuring easy cleaning and hygiene, and is highly durable, resisting deformation.
Front and Rear Suspension System
A specially designed front and rear suspension system that absorbs the bumps from uneven surfaces, providing a more comfortable riding experience.
Extra-large storage space
A dedicated storage bag with a capacity of 5 liters is located at the bottom, making travel convenient.
Multinational Certifications
US Food and Drug Administration (FDA) registered medical device product, complies with ISO7176, EN12184, and IEC60601.
FDA Registered
ISO 7176
EN 12184
IEC60601
Specifications
Model :
Z ALUMINIUM – ZA1
Weight :
17kg (Net weight)) / 19kg (Including the battery)
Maximum Load Capacity :
≤ 100kg
Maximum Speed :
≤ 6km/h
Maximum Range :
≥ 15km / ≥ 30km
Motor Power :
180W*2
Charging Time :
4 hrs / 7 hrs
Climbing Angle :
7°(12%)
Braking Angle :
7°(12%)
Front Wheel Size :
16.5cm(6.5inch)
Rear Wheel Size :
28cm(11inch)
Minimum Turning Radius :
63cm(Without footrest) / 75cm(With footrest)
Maximum Unfolded Dimensions :
93 x 60 x 93cm
Seat Size :
40x 40cm
