Carbon Fiber Made , Fold-in-half design , Ultimate Lightweight

Carbon Fiber Made , Fold-in-half design , Ultimate Lightweight

3-Second Folding

Lightweight and folds in just 3 seconds for ultimate portability and storage. Quick 3-second fold and lightweight design allow for easy transport and storage, wherever you go.

14kg Total Weight

Featuring a carbon fiber frame, this wheelchair weighs only 15.35kg with the battery, offering a lightweight yet sturdy design with a safe load capacity of 100kg.

14kg Total Weight

Featuring a carbon fiber frame, this wheelchair weighs only 15.35kg with the battery, offering a lightweight yet sturdy design with a safe load capacity of 100kg.

Foldable Armrest Design

Providing a 3-way entry and dining-on-the-device feature, able to reduce the pressure of the caregivers.

Abundant Power

With its abundant 250W*2 power, it can achieve a climbing angle of 12 degrees (20% slope), surpassing the competition by far.

Abundant Power

With its abundant 250W*2 power, it can achieve a climbing angle of 12 degrees (20% slope), surpassing the competition by far.

Front Suspension System

A specially designed front suspension system that absorbs the bumps from uneven surfaces, providing a more comfortable riding experience.

Front Suspension System

A specially designed front suspension system that absorbs the bumps from uneven surfaces, providing a more comfortable riding experience.

Fully enclosed wheels

Beauty, Safety and Easy-to-clean.

Wireless remote control driving

Option to purchase the wireless remote which enables users to drive and through a Bluetooth-encrypted wireless remote control. Can be also used for transporting items.

Wireless remote control driving

Option to purchase the wireless remote which enables users to drive and through a Bluetooth-encrypted wireless remote control. Can be also used for transporting items.

Incomparable user experience

A 7-speed level setting and speed display controller that provides a simple, intuitive, and comfortable control experience.

Dedicated Phone Holder

Made of carbon fiber, lightweight and durable. Easy to adjust pitch angle and direction according to user′s needs.

High Performance

Long-Lasting Battery

Suitable For Traveling

EABS Electromagnetic Brake

Multinational Certifications

Complies with ISO7176, EN12184, and IEC60601.

ISO 7176

EN 12184

IEC60601

Specifications

Model :

X Carbon – XC1

Weight :

14kg (Net weight) / 15.35kg (Including the battery) / 16.1kg (Includes high-capacity battery)

Maximum Load Capacity :

≤ 100kg

Maximum Speed :

≤ 6km/h

Maximum Range :

≥ 20km

Motor Power :

Rated 500W (250W*2), Peak 800W

Charging Time :

4hrs

Climbing Angle :

≤ 12°(20%)

Braking Angle :

≤ 12°(20%)

Front Wheel Size :

16.5cm(6.5inch)

Rear Wheel Size :

28cm(11inch)

Minimum Turning Radius :

63cm(Without footrest) / 75cm(With footrest)

Maximum Unfolded Dimensions :

98 x 58 x 88cm

Seat Size :

40 x 40cm

Experience the World,
Unrestricted Barriers
